型号 Model/项目 Item | HLS60 | HLS90 | HLS120 | HLS150 | HLS180 | HLS200 | |
整机 Whole machine |
理论生产率(m³/h) Theoretical productivity |
60 | 90 | 120 | 150 | 180 | 200 |
控制方式 Control mode |
微机 Computer | ||||||
计量方式 Weighing mode |
电子称 Electrical scale | ||||||
出料高度(m) Discharging height |
3.8 | ||||||
整机装机容量(kw) Whole machinery capacity |
140 | 165 | 200 | 240 | 255 | 370 | |
搅拌机 Mixer |
搅拌机型号 Model of mixer |
MT1500/1000 | MT2250/1500 | MAO3000/2000 | MAO4500/3000 | MAO4500/3000 | MAO6000/4000 |
搅拌机功率(kw) Mixing power |
18.5×2 | 30×2 | 37×2 | 55×2 | 55×2 | 75×2 | |
入料容积(L) Charging volume |
1600 | 2500 | 3200 | 4600 | 4600 | 6500 | |
出料容积(L) Discharging volume |
1000 | 1500 | 2000 | 3000 | 3000 | 4000 | |
粒径碎石/卵石(mm) Diameter of macadam/pebble |
40~80 | 40~80 | 40~100 | 40~100 | 40~100 | 40~100 | |
骨料储系统 |
|||||||
配料秤型号 Batcher scale model |
DPL2400A | DPL2400B | DPL3200 | DPL4800A | DPL4800 | DPL6400 | |
配料种类 Types of ingredients |
3Piece(种) | 3~4Piece(种) | 4Piece(种) | 4Piece(种) | 4Piece(种) | 4Piece(种) | |
砂石储料仓容积(m³) Aggregate storage hopper volume |
8×3 | 15×3~4 | 20×4 | 25×4 | 25×4 | 地仓 | |
计量范围及精度 Weighing range & accuracy |
200~3000±2% | 1800×3~ 3±2% | 2200×4~±2% | 3500×4~±2% | 3500×4~±2% | 4800×4~±2% | |
水平皮带机输送能力(t/h)Horizontal belt conveyor capacity | 280 | 480 | 480 | 800 | 800 | 1000 | |
粉料储供系统 Powder storage system |
倾角皮带机输送能力(t/h) Slant belt conveyor capacity |
350 | 600 | 600 | 1000 | 1000 | 1100 |
粉料存储能力(t) Powder storage capacity |
100×2 | 100×3 | 100×4 | 200×4 | 200×4 | 300×4 | |
螺旋输送机能力(t/h) Screw conveyor capacity |
55 | 70 | 80 | 110 | 110 | 150 | |
水泥计量范围及精度 Cement weighing range & accuracy |
100~600±1% | 200~1000±1% | 200~1200±1% | 200~1600±1% | 200~1600±1% | 200~1200±1% | |
粉煤灰及粉状外加剂范围及精度 Coal flyash storage system |
50~200±1% | 50~350±1% | 50~500±1% | 50~800±1% | 50~800±1% | 50~800±1% | |
水外加剂储供系统 Water additives storage system |
水计量范围(kg) Water weighing range |
50~400 | 50~500 | 50~500 | 50~800 | 50~800 | 50~1000 |
水计量精度 Water weighing accuracy |
±1% | ||||||
液态外加剂量范围(kg) Liquid additives weighing range |
5~30 | 5~60 | 5~60 | 5~80 | 5~80 | 5~80 | |
液态外加剂量精度 Liquid additives weighing accuracy |
±1% |
