项目 Item/型号 Model | YHZS25 | YHZS35 | YHZS50 | YHZS75 | |
整机 Whole machine |
理论生产率(m³/h) Theoretical productivity |
25 | 35 | 50 | 75 |
控制方式 Control mode |
微机 Computer | ||||
计量方式 Weighing mode |
电子称 Electrical scale | ||||
出料高度(m) Discharging height |
2.8~3.8 | ||||
整机装机容量(kw) Whole machinery capacity |
50 | 80 | 100 | 140 | |
搅拌机 Mixer |
搅拌机型号 Model of mixer |
JS500 | JS750 | JS1000 | MT1250 |
搅拌机功率(kw) Mixing power |
18.5 | 30 | 18.5×2 | 22×2 | |
入料容积(L) Charging volume |
800 | 1200 | 1500 | 1750 | |
出料容积(L) Discharging volume |
500 | 800 | 1000 | 1250 | |
料径碎石/卵石(mm) Diameter of macadam/pebble |
40~60 | 40~60 | 40~80 | 40~80 | |
骨料储供系统 Aggregate storage system |
配料秤型号 Batcher scale model |
PL 800 | PL1200 | PL1600 | PL2400 |
配料种类 Types of ingredients |
2Piece(种) | 2Piece(种) | 4Piece(种) | 4Piece(种) | |
计量范围及精度 Weighing range & accuracy |
200~1500±2% | 200~2000±2% | 200~2500±2% | 200~3500±2% | |
粉料储 供系统 Powder storage system |
粉料存储能力(t) Powder storage capacity |
50×1 | 50×1 | 50×1 | 50×2 |
螺旋输送机能力(t/h) Screw conveyor capacity |
30 | 35 | 45 | 55 | |
水泥计量范围及精度 Cement weighing range & accuracy |
50~300±1% | 50~450±1% | 50~600±1% | 100~800±1% | |
水外加剂 储供系统 Water additives storage system |
水计量范围(kg) Water weighing range |
50~150 | 50~200 | 50~350 | 50~450 |
水计量精度 Water weighing accuracy |
±1% | ||||
液态外加剂量范围(kg) Liquid additives weighing range |
5~20 | 5~20 | 5~20 | 5~30 | |
液态外加剂量精度 Liquid additives weighing accuracy |
±1% |
