配料机系列
CONCRETE BATCHER SERIES
混凝土配料机主要技术参数 MAIN TECHNICAL PARAMETERS FOR CONCRETE BATCHER
型号 Model/参数项目Item Parameters | PL800 | PL1200 | PL1600 | PL2400 | PL2400A | PL2400B | PL3200 |
称量斗容积(m³) Measuring hopper volume |
0.85 | 1.25 | 1.8 | 2.4 | 2.4 | 3×1.5 | 4×1.9 |
储料斗容积(m³) Storage hopper volume |
2×2.2 | 3×3.4 | 3×5 | 3×8 | 3×15 | 3×20 | 4×20 |
生产率(m³/h) Productivity |
45 | 60 | 80 | 120 | 120 | 300 | 450 |
配料精度 Blending accuracy |
±2% | ||||||
最大称量值(kg) Max measuring value |
1500 | 2000 | 2500 | 3500 | 3×1800 | 4×2200 | |
可配料种数 Blending types |
2 | 3-4 | 3 | 3 | 3 | 3-4 | 4 |
上料高度(mm) Loading height |
2500 | 2500 | 3100 | 3500 | 3960 | 4200 | 4400 |
皮带机带速(m/s) Belt conveyor belt speed |
1.25 | 1.25 | 1.75 | 1.6 | 1.25 | 1.25 | 1.25 |
功率(kw) Power |
2.2×3 | 2.2×4-5 | 4×4 | 7.5 | 11 | 11 | 11 |
整机重量(kg) Total weight |
2500 | 5280 | 5100 | 5700 | 8522 | 15000 | 19000 |
外形尺寸(mm) (长×宽×高) Outline dimensions (length*width*height) |
5640×1590×2671 | 11252×2177×3050 | 9042×2690×3451 | 9800×2748×4000 | 9930×3123×4300 | 11190×3700×6090 | 14820×3700×6090 |
